Start/Stop System Overview

Start/Stop System Overview






1 Voltage Stabilizer (J532)

• Removing and installing, refer to => [ Voltage Stabilizer (J532) ] Starting and Charging.

2 Nut

• 3 Nm

3 Nut

• 3 Nm

4 Cover/ Multimedia Control Head (E380)

5 Start/Stop Mode Button (E693)

• Various installed locations

• Removing and installing, refer to => [ Start/Stop Mode Button ] Start/Stop Mode Button.

6 Nut

• 3 Nm

7 Bracket

• For the voltage stabilizer.

8 Electrical Connector
