Fog/Driving Lamp Switch: Service and Repair

REMOVAL PROCEDURE
1. Remove the trim plate from the instrument panel cluster.
2. Disconnect the electrical connectors (3 and 4).
3. Remove the fog lamp switch.

INSTALLATION PROCEDURE
1. Connect the electrical connectors (3 and 4).
2. Install the fog lamp switch.
3. Install the trim panel to the instrument panel cluster.
