Fill Valve Access Cover Replacement

REMOVAL PROCEDURE




1. Remove the rear bumper fascia.
2. Loosen the fill valve access cover nuts.
3. Remove the fill valve access cover.

INSTALLATION PROCEDURE




1. Install the fill valve access cover.

NOTE: Refer to Fastener Notice in Service Precautions.

2. Adjust the fill valve access cover.

Tighten
Tighten the till valve access cover retaining nuts to 12 N.m (108 lb in).

3. Install the rear bumper fascia.
