Fog Lamp - Installation

INSTALLATION





1. Position the fog lamp (1) in the fascia opening.
2. Install the two fog lamp unit mounting fasteners.
3. Connect the electrical connector.





4. Install the headlamp assembly (3).Front Lamp Unit - Installation





5. Install the front fascia. Front Bumper Fascia - Installation.
6. Connect the battery negative cable.
