Overhead Console

REMOVAL
1. Disconnect the battery ground cable.







2. Open the sunglass storage compartment.







3. Remove the overhead console screw.
4. Remove the overhead console.
^ Disconnect the electrical connectors.

NOTE: Disengage the four clip attachments by first pulling down on the front end of the overhead console and then the rear end of the overhead console.

INSTALLATION
1. To install, reverse the removal procedure.
