A/T - 4EAT Diagnostic Procedure

Article No.
92-18A-1

09/04/92

^ ENGINE FUEL CONTROL SYSTEM - 4EAT TRANSAXLE DIAGNOSTIC PROCEDURE - SHOP MANUAL CORRECTION

^ TRANSAXLE - 4EAT DIAGNOSTIC PROCEDURE - SHOP MANUAL CORRECTION

FORD:
1989 PROBE

ISSUE:
Some of the diagnostic procedures for the 4EAT transmission as published in the 1989 Probe Shop Manual, Sections 17-01 and 55-04 are incorrect.

ACTION:
If service is required, use the diagnostic procedures on pages 21 through 27 of this TSB article. This information should be inserted in your 1989 Probe Shop Manual, Sections 17-01 and 55-04.

OTHER APPLICABLE ARTICLES: 89-2-10
SUPERSEDES: 88-16-12, 88-17-9
WARRANTY STATUS: INFORMATION ONLY
OASIS CODES: 501000, 502000, 590000, 690000





Page 17-01-17





Page 17-01-18





Page 55-04-5





Page 55-04-6





Page 55-04-11





Page 55-04-12





Page 55-04-84
