Rotor Replace

Front Rotor Removal and Installation







1. Remove tire and wheel assembly.
2. Remove brake caliper from mount.
3. Remove caliper mount.
4. Remove rotor.

Reverse procedure to install. Torque caliper mount to 76 ft.lbs.. Torque caliper retaning bolts to 36 ft.lbs.
