Reassembly

NOTE: Refer to above figure for reassembly sequence.




1. Support 2nd gear on steel blocks as shown, then install the 3rd/4th synchro hub using the special tools and a press as shown.




2. Install the 5th synchro hub using the special tools and a press as shown.




3. Install the ball bearing using the special tools and a press as shown.
