Inspection

1. Check the production date on the FMVSS door label to determine if vehicle falls within the production range.





2. Use the Hi-Scan Pro to identify the ECM calibration in the vehicle by entering "SEDONA", "ENGINE CONTROL", ECU ROM I.D.

^ If the calibration identification on line 1 is "8105 F6", then the vehicle has the latest calibration - DO NOT REPROGRAM.

^ If the calibration identification is "8105 F4 or "8105 F2", proceed to Reprogramming Procedure.
