Outlet

Radiator Hose Replacement - Outlet

^ Tools Required
- J 38185 Hose Clamp Pliers

Removal Procedure





1. Drain the cooling system.
2. Use J 38185 in order to reposition the hose clamp from the water pump housing.
3. Remove the radiator outlet hose (3) from the water pump housing (1).
4. Raise and support the vehicle. Refer to Vehicle Lifting.
5. Remove the lower air deflector.





6. Use J 38185 in order to reposition the hose clamp from the radiator.
7. Remove the outlet hose from the radiator.

Installation Procedure





1. Align the marks on the hose and Install the outlet hose to the radiator.
2. Use J 38185 in order to reposition and install the hose clamp to the radiator.
3. Install the lower air deflector.
4. Lower the vehicle.





5. Align the marks on the hose and install the radiator outlet hose (3) to the water pump housing (1).
6. Use J 38185 in order to reposition and install the hose clamp to the water pump housing
7. Fill the cooling system.
