Technical Data, Air Conditioning System

Technical values







Climatronic technical data (right/left)
- Refrigerant quantity (R 134a): - : 700 g
- Refrigerant oil in compressor: - : 140 ±10 cm (cubic)
- High-pressure cut-off: - : 32 bar
- Low-pressure cut-off: - : 1 bar
- Pressure relief valve purge pressure: - : 44 ±4 bar

Climatronic 2+2 technical data
- Refrigerant quantity (R 134a): - : 1050 g
- Refrigerant oil in compressor: - : 140 ±10 cm (cubic), plus - : 100 ±10 cm (cubic)
- High-pressure cut-off: - : 32 bar
- Low-pressure cut-off: - : 1 bar
- Pressure relief valve purge pressure: - : 44 ±4 bar
